Airframe
Total Hours:
575
Total Cycles:
0
575 Hours Since New
No Damage History
Max Cruise: 140 KTAS
Service Ceiling: 18,000 Feet
Takeoff Performance: 1457 ft
1808 lbs – Empty Weight
2645 lbs – Maximum Takeoff Weight
837 lbs – Useful Load
4 Seats/3 Cabin Doors/1 Baggage Door
28V/60ah Alternator
24V/8ah Battery
LED Nav/Strobe Lights
LED Taxi/Landing Lights
Mountain High Portable Aviation Oxygen System
-1 Pilot Face Mask w/Microphone
-3 Breathing stations XCP-MH4
-Installation kit
No Damage History
Max Cruise: 140 KTAS
Service Ceiling: 18,000 Feet
Takeoff Performance: 1457 ft
1808 lbs – Empty Weight
2645 lbs – Maximum Takeoff Weight
837 lbs – Useful Load
4 Seats/3 Cabin Doors/1 Baggage Door
28V/60ah Alternator
24V/8ah Battery
LED Nav/Strobe Lights
LED Taxi/Landing Lights
Mountain High Portable Aviation Oxygen System
-1 Pilot Face Mask w/Microphone
-3 Breathing stations XCP-MH4
-Installation kit
Engines
Continental CD-170
170hp, 5.2 gph @ 140KTAS
Liquid Cooled, 4 Cylinder, Four Stroke Diesel with DOHC
Fully Automated Digital Engine Control (FADEC)
575 Hours Since New
170hp, 5.2 gph @ 140KTAS
Liquid Cooled, 4 Cylinder, Four Stroke Diesel with DOHC
Fully Automated Digital Engine Control (FADEC)
575 Hours Since New
Avionics
Garmin G1000 Nxi Includes:
GDU 1050 10-inches PFD
GDU 1050 10-inches MFD
Dual GEA 71 Engine & Airframe unit
Dual GIA 64WAAS Com/nav/GPS/GS/Loc
GMA 1347 Digital audio system
GMU 44 Magnetometer
GDC 72 Air data computer
GRS 79 AHRS
GTP 59 OAT
GTX 345R Mode S Transponder (ADS-B In
and OUT)
GFC 700 Autopilot Including Electronic
Stability & Protection (ESP)
Garmin TAS 800 Active Traffic
Synthetic Vision Technology
Garmin FlightStream 510
MD 302 Standby Attitude Module
GDU 1050 10-inches PFD
GDU 1050 10-inches MFD
Dual GEA 71 Engine & Airframe unit
Dual GIA 64WAAS Com/nav/GPS/GS/Loc
GMA 1347 Digital audio system
GMU 44 Magnetometer
GDC 72 Air data computer
GRS 79 AHRS
GTP 59 OAT
GTX 345R Mode S Transponder (ADS-B In
and OUT)
GFC 700 Autopilot Including Electronic
Stability & Protection (ESP)
Garmin TAS 800 Active Traffic
Synthetic Vision Technology
Garmin FlightStream 510
MD 302 Standby Attitude Module
Props
Prop Information
MT 3-Blade Composite Propeller
Constant Speed Propeller
Constant Speed Propeller
Additional Equipment/Features
Dual Flight Controls
Castering Nose Wheel
Rudder/Aileron Lock
Hydraulic Toe Brakes
Advanced Wheel Fairings
Parking Brakes
Electric Flaps
External Power Supply Receptecle
LED Taxi/Landing Light
LED Nav/Strobe Light
Fuselage Cover
Safety Features:
GFC700 Autopilot with Enhanced Stability and Protection
Garmin Synthetic Vision
Digital 4-in-1 Standby Instrument
Heated Pitot System
Alternate Static Souce
ADS-B Garmin Transponder
406 MHz ELT
Terrain Awareness and Warning System (eTAWS)
Seatbelts
ALL SPECIFICATIONS SUBJECT TO VERIFICATION UPON INSPECTION
Castering Nose Wheel
Rudder/Aileron Lock
Hydraulic Toe Brakes
Advanced Wheel Fairings
Parking Brakes
Electric Flaps
External Power Supply Receptecle
LED Taxi/Landing Light
LED Nav/Strobe Light
Fuselage Cover
Safety Features:
GFC700 Autopilot with Enhanced Stability and Protection
Garmin Synthetic Vision
Digital 4-in-1 Standby Instrument
Heated Pitot System
Alternate Static Souce
ADS-B Garmin Transponder
406 MHz ELT
Terrain Awareness and Warning System (eTAWS)
Seatbelts
ALL SPECIFICATIONS SUBJECT TO VERIFICATION UPON INSPECTION
Interior
Interior Premium Edition
Pilot and Co-Pilot Seats Leather
– Electrically Adjustable Fore and Aft
– Vertical Adjustment
Two Rear Passenger Seats Leather
Seat Belts & Shoulder Harness, All Seats
Fire Extinguisher
Cabin Heat/Defrost
Soundproofing
Luggage Compartment
Overhead Cockpit Speaker
Four Position Intercom System
Pilot and Co-Pilot Seats Leather
– Electrically Adjustable Fore and Aft
– Vertical Adjustment
Two Rear Passenger Seats Leather
Seat Belts & Shoulder Harness, All Seats
Fire Extinguisher
Cabin Heat/Defrost
Soundproofing
Luggage Compartment
Overhead Cockpit Speaker
Four Position Intercom System
Exterior
Two Tone Polyurethane Exterior Paint
Metalic Paint
Epoxy Corrosion Proofing
LH/RH Front Door Pilot/Co-Pilot
Rh Rear Door Passenger
Rh Baggage Door With Lock
All Lateral Windows Tinted
Tie Down Rings
Main Wheels, 6.00 X 6
Nose Wheel, 5.00 X 5
Metalic Paint
Epoxy Corrosion Proofing
LH/RH Front Door Pilot/Co-Pilot
Rh Rear Door Passenger
Rh Baggage Door With Lock
All Lateral Windows Tinted
Tie Down Rings
Main Wheels, 6.00 X 6
Nose Wheel, 5.00 X 5
