2007 Hawker 400XP
Price: $1,895,000 Sale Pending!
- Serial Number: RK-514
- Tail Number: N76GJ
- Hours: 5,394
- Cycles: 3,907
Engines Enrolled on Vector Aerospace - VMAX Gold Program
Airframe enrolled on Textron Increased Flight Activity Inspection Program
Paint & Interior refurbished in 2017
GoGo WiFi Equipped
Airframe enrolled on Textron Increased Flight Activity Inspection Program
Paint & Interior refurbished in 2017
GoGo WiFi Equipped
Airframe
Total Hours:
5,394
Total Cycles:
3,907
Entry Into Service Date:
March, 2007
Home Base:
RVS
Maintenance Tracking:
CAMP
Airframe Certification:
FAR Part 91
Total Time Since New: 5,394 (As of June 15, 2021)
Total Cycles Since New: 3,907 Cycles
Manufacture Date: 2007
Home Base: Tulsa, OK Riverside Airport (KRVS)
Maintenance Tracking: CAMP
Current Regulation: Operated Under FAA Part 91 Regulation
Total Cycles Since New: 3,907 Cycles
Manufacture Date: 2007
Home Base: Tulsa, OK Riverside Airport (KRVS)
Maintenance Tracking: CAMP
Current Regulation: Operated Under FAA Part 91 Regulation
Engines
Pratt & Whitney JT15D-5R
Engine 1
Serial Number:
PCEJG0013
Hours Since New:
5,251
Cycles Since New:
3,779
Engine 2
Serial Number:
PCEJG0014
Hours Since New:
5,251
Cycles Since New:
3,779
Avionics
ADS-B Out Equipped:Yes
WAAS Equipped:Yes
LPV Equipped:Yes
A/P (Autopilot): Single Collins APS-4000
ADC (Air Data Computers): Dual Collins ADC-850D
ADF (Automatic Direction Finder): Dual Collins ADF-462
AHRS (Attitude and Heading Reference System): Dual Collins AHC-85E
AUDIO PANEL: Dual DB System 438
CVR (Cockpit Voice Recorder): Single L-3 FA-2100 (30 Minutes)
DME (Distance Measuring Equipment): Dual Collins DME-442
EFIS (Electronic Flight Instrument System): Triple Collins EFD-871
ELT (Emergency Locator Beacon): Single Artex C406-2
FMS (Flight Management System): Dual Collins AMS-5000
GPS (Global Positioning System): Single Collins GPS-4000 w/WAAS
GPWS (Ground Proximity Warning System): Single Honeywell Mark V w/Windshear Detection
MFD (Multi-Function Display): Single Garmin GMX 200
NAV (Navigation Radio): Dual Collins VIR-432A
RADAR: Single Collins TWR-850
RADAR ALT (Radar Altimeter): Single Collins ALT-1000
RMU (Radio Management Unit): Dual Collins RTU-870F
SAI (Standby Attitude Indicator): Single L-3 (Goodrich)
TCAS (Traffic Collision Avoidance System): Single Collins TCAS-4000 w/Change 7
VHF COM (Very High Frequency Communications): Dual Collins VHF-422 w/8.33 kHz Spacing
XM WX (XM Satellite Weather): Single Garmin GDL-69
XPNDR (Transponder): Dual ACSS NXT-600
ADC (Air Data Computers): Dual Collins ADC-850D
ADF (Automatic Direction Finder): Dual Collins ADF-462
AHRS (Attitude and Heading Reference System): Dual Collins AHC-85E
AUDIO PANEL: Dual DB System 438
CVR (Cockpit Voice Recorder): Single L-3 FA-2100 (30 Minutes)
DME (Distance Measuring Equipment): Dual Collins DME-442
EFIS (Electronic Flight Instrument System): Triple Collins EFD-871
ELT (Emergency Locator Beacon): Single Artex C406-2
FMS (Flight Management System): Dual Collins AMS-5000
GPS (Global Positioning System): Single Collins GPS-4000 w/WAAS
GPWS (Ground Proximity Warning System): Single Honeywell Mark V w/Windshear Detection
MFD (Multi-Function Display): Single Garmin GMX 200
NAV (Navigation Radio): Dual Collins VIR-432A
RADAR: Single Collins TWR-850
RADAR ALT (Radar Altimeter): Single Collins ALT-1000
RMU (Radio Management Unit): Dual Collins RTU-870F
SAI (Standby Attitude Indicator): Single L-3 (Goodrich)
TCAS (Traffic Collision Avoidance System): Single Collins TCAS-4000 w/Change 7
VHF COM (Very High Frequency Communications): Dual Collins VHF-422 w/8.33 kHz Spacing
XM WX (XM Satellite Weather): Single Garmin GDL-69
XPNDR (Transponder): Dual ACSS NXT-600
Navigation and Compliance
RVSM Equipped:Yes
ADS-B Out
RVSM
TCAS 2000
WAAS/LPV/GPS
RVSM
TCAS 2000
WAAS/LPV/GPS
Inspections
Inspection Type
Performed
Next Due
A-Phase
Performed:
August 2021
Next Due:
August 2022
B-Phase
Performed:
4,692 Hours
Next Due:
5,492 Hours
C-Phase
Performed:
4,692 Hours
Next Due:
6,292 Hours
D-Phase
Next Due:
6,400 Hours
Additional Equipment/Features
Cabin 115VAC / 60Hz Outlets
Freon Air Conditioning
Lead Acid Battery
Angle of Attack Indicator
Anti-Ice
Thrust Reversers
Freon Air Conditioning
Lead Acid Battery
Angle of Attack Indicator
Anti-Ice
Thrust Reversers
Interior
Number Of Passengers:
8
Forward Galley: Yes
Aft Lavatory: Yes
Interior Last Refurbished:
2017
Seating Capacity: 7 Seats + Belted Lavatory
Galley Location: Forward
FWD Cabin Configuration: (1) One Right Side Rear Facing Executive Seat and (4) Four Seat Club with Fold Out Tables
AFT Cabin Configuration: (2) Two Forward Facing Executive Seats
Lavatory Location(s): (1) One Aft Belted Lavatory
Electrical Outlets: (2) Cabin 110VAC/60Hz Outlets
Plating: Nickel
Additional Galley Equipment: Ice Bin, Hot Liquid Container and Multi-Compartment Storage
Carpet: Light Tundora Grey
Woodwork: Rich Espresso
Soft Goods: Silver Pearl Ultra-leather Seats
Last Interior Completion: 2017
Interior Completion Facility: Eagle Aviation
Interior Completion Location: Columbia, SC
Galley Location: Forward
FWD Cabin Configuration: (1) One Right Side Rear Facing Executive Seat and (4) Four Seat Club with Fold Out Tables
AFT Cabin Configuration: (2) Two Forward Facing Executive Seats
Lavatory Location(s): (1) One Aft Belted Lavatory
Electrical Outlets: (2) Cabin 110VAC/60Hz Outlets
Plating: Nickel
Additional Galley Equipment: Ice Bin, Hot Liquid Container and Multi-Compartment Storage
Carpet: Light Tundora Grey
Woodwork: Rich Espresso
Soft Goods: Silver Pearl Ultra-leather Seats
Last Interior Completion: 2017
Interior Completion Facility: Eagle Aviation
Interior Completion Location: Columbia, SC
Entertainment
Display TV Monitors:
10.4” LCD Monitor
Cabin Display: 10.4” LCD Monitor
Display Location(s): FWD & AFT
Display Location(s): FWD & AFT
Exterior
Base Paint Colors:
Matterhorn White
Stripe Colors:
Medium & Charcoal Gray
Last Painted:
2017
Paint Facility Name: Eagle Aviation
Paint Facility Location: Columbia, SC
Paint Facility Location: Columbia, SC
